Y30 Ferrite Motor Permanent Magnets Strontium Wiper Motor Of Automobiles

JOINT-MAG Magnetic Materials Co., Ltd. Zigong
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Y30 Ferrite Motor Permanent Magnets Strontium Wiper Motor Of Automobiles

Brand Name : JOINT-MAG

Model Number : OEM

Certification : IATF 16949

Place of Origin : Sichuan, China (Mainland)

MOQ : Negotiable

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 5000T Annual Capacity

Packaging Details : 5000T Annual Capacity

Product Name : Wiper Motor Permanent Ferrite Magnet

Model NO. : For various types of Wiper

Transport Package : Carton Wooden Pallet

Trademark : JOINT-MAG, Joint-Mag

Origin : Sichuan, China (Mainland),

Grade : JC-Y3932; JC-Y3939; JC-Y4041; JC-Y4127; JC-Y4231; JC-Y3744; JC-Y3849; JC-Y4240

Contact Now

Strontium Wiper Motor Permanent Magnet Y30 Y33 Automobiles

Product Description

Materials

Made of SrO. 6Fe2O3 and other trace elements.
Strontium ferrite powders have been designed for the production of all grades of hard ferrite. We will get high quality by adding proper additives to the powder. Our strict quality control system ensures stable and reliable quality.
Available product styles: arc, line segment, block



Grade:

JC-Y3932; JC-Y3939; JC-Y4041; JC-Y4127; JC-Y4231; JC-Y3744; JC-Y3849; JC-Y4240 etc...M

agnetic property

Br can reach 430 KA/m Hcb can reach 310 KA/m,

Hcj can reach 395 KA/m (BH)max can reach 3.6 kJ/m3



Description:

Permanent Magnet For Wiper Motors

Material

SrO. 6Fe2O3

Product Name

Ferrite Magnet, Ceramic Magnet

Working Temperature

Grade

Temperature



Y10T

250ºC



Y25

250ºC



Y30

250ºC



Y33

250ºC



Y35

250ºC



Y30BH

250ºC



Y33BH

250ºC

Magnet Shape:

Disc,Cylinder,Block,Ring,Countersunk,Segment,Trapezoid and Irregular shapes and more.Customized shapes are available

Features:

A low cost alternative to other magnetic materials, offers relatively high operating temperatures and good resistance to corrosion
& demagnetization. However, it has lower energy levels (Br) and is brittle in nature.

Applications:

Dc motors, Louderspeaks, Magnetic Separators, Automotive Sensors, Educations, Wiper Motors,etc


Packaging & Delivery

Packaging Details
Carton: Tray Wooden
Special Package for your requestDelivery TimeAccording to your request

Specifications

1, permanent magnet for Wiper motors of Automobiles
2, JC/Y3932, JC/Y3939, JC/Y4041
3, Past ISO/TS16949: 2009
4, Competitive price

Y30 Ferrite Motor Permanent Magnets Strontium Wiper Motor Of AutomobilesY30 Ferrite Motor Permanent Magnets Strontium Wiper Motor Of Automobiles

About Us



In October 2004, It was conferred with High-tech Product Certificate, awarded as a High-tech Enterprises in Sichuan by Sichuan Provincial Science and Technology Department in December 2004, and First Price of Sichuan SME Technology Innovation Award in December 2004.



In July 2004, our new JC-Y4240 performance (equivalent to Japan TDK FN6B performance level) of ferrite permanent technology was identified and approved by the experts from Science and Technology Department of the Sichuan Province. The declared High Performance Ferrite Permanent Magnet (JC4545)has been listed among Key Science and Technological Program of Sichuan Province and has been given financial support.



In 2007, Technology of manufacturing high-performance ferrite permanent magnet with YF30 pre-sintering materials. We were awarded with the tile of Outstanding Technical Achievements and Outstanding Products by the National Materials and Devices industry associations.



Our advantages
Our corporate philosophy has always focused on first-class quality and service.
We also stress high efficiency in our workplace. We respect our clients by promptly responding to order requests or general inquiries.
We aim to provide you with the best possible after sales service. We never stop working for you, even after fulfilling your order.
